AP440FX MotherboardTechnical Product SpecificationThe AP440FX motherboard may contain design defects or errors known as errata which may cause the pro

AP440FX Motherboard Technical Product Specification101.4 I/O ShieldThe back panel I/O shield for the AP440FX motherboard must meet specific dimensiona

Motherboard Description111.5 MicroprocessorThe AP440FX motherboard operates with 2.1 V to 3.5 V Pentium Pro processors. An onboardvoltage regulator c

AP440FX Motherboard Technical Product Specification121.6 Main System MemoryThe motherboard has four 72-pin tin-lead SIMM sockets that make it possibl

Motherboard Description13• Integrated DRAM controller 64/72-bit Non-Interleaved path to memory w/ ECC support Support for EDO and Fast Page DRAM

AP440FX Motherboard Technical Product Specification141.7.4 IDE SupportThe motherboard provides two independent high performance bus-mastering PCI IDE

Motherboard Description151.8 PC87307 Super I/O ControllerControl for the integrated serial ports, parallel port, floppy drive, real-time clock, and k

AP440FX Motherboard Technical Product Specification16• <CTRL> <ALT> <defined in Setup>: Power down and coffee-break key sequences

Motherboard Description171.9.1 S3 ViRGE Graphics SubsystemThe AP440FX motherboard is available with a factory option of an S3 ViRGE SVGA graphicscont

AP440FX Motherboard Technical Product Specification181.9.2 S3 ViRGE/DX Graphics SubsystemThe optional onboard graphics subsystem uses the S3 ViRGE/DX

Motherboard Description191.10 Audio SubsystemThe AP440FX motherboard features a 16-bit stereo audio subsystem as a factory installed option.The audio

Revision HistoryRevisionRevision History Date-001Release of the AP440FX Technical Product Specification. 7/96-002Second release of the AP440FX Technic

AP440FX Motherboard Technical Product Specification20When an out-of-range condition (temperature, fan speed, or voltage) is reached, an interrupt isac

Motherboard Description21Bank 0(J6J1, J7J1)Bank 1(J7J2, J7J3)PCI/ISA RiserConnector(J6J2)OM06182Audio1J9N1CD-ROM4Power1J9J13.3VPower61J9H1PrimaryPower

AP440FX Motherboard Technical Product Specification221.12.1 Front Panel ConnectorsThe AP440FX motherboard provides connectors to support functions ty

Motherboard Description231.12.1.1 SW_ONThis 2-pin header connects to a front panel power switch. When the switch is closed, the powersupply turns on.

AP440FX Motherboard Technical Product Specification241.12.1.6 ResetThis 2-pin header can be connected to a momentary SPST type switch that is normally

Motherboard Description251.12.2 Memory/Expansion ConnectorsThe AP440FX motherboard has four 72-pin SIMM sockets for main memory. These socketsaccept

AP440FX Motherboard Technical Product Specification26Table 7. PCI/ISA Riser Connector (J6J2) (continued)Pin Signal Name Pin Signal Name Pin Signal Pin

Motherboard Description271.12.3 VESA Feature ConnectorTable 8 provides the pinout and signal listing for the LBP VESA feature connector.Table 8. LBP

AP440FX Motherboard Technical Product Specification281.12.5 Audio ConnectorsThe pinouts and signal listings for the audio connectors are provided in T

Motherboard Description291.12.6 Power Supply ConnectorsThe AP440FX motherboard must be used with a power supply that supports remote power on/off,so

iiiTable of Contents1 Motherboard Description1.1 Overview...

AP440FX Motherboard Technical Product Specification30The pinout listing for the soft-off power supply connector of the AP440FX motherboard is shownin

Motherboard Description31Table 17 lists the pinout and signal names for the IDE connectors.Table 17. IDE Connectors (J8H1, J9H2)Pin Signal Name Pin Si

AP440FX Motherboard Technical Product Specification321.12.8 Back Panel ConnectorsFigure 7 shows the location of the back panel connectors.OM06183PS/2

Motherboard Description331.12.8.2 COM1 Serial PortTable 19 lists the pinout and signal names for the serial connectors.Table 19. Serial Port Connecto

AP440FX Motherboard Technical Product Specification341.12.8.5 Parallel PortTable 22 lists the pinout and signal names for the parallel port connector.

Motherboard Description351.13 Jumper SettingsThere are three jumper blocks on the AP440FX motherboard. The jumper block at J1J1 defines thenumber of

AP440FX Motherboard Technical Product Specification361.13.1 Microprocessor Configuration (J4L2)These allow the motherboard to be switched between dif

Motherboard Description37Table 24 lists the motherboard configuration jumper positions and indicates the meaning for eachposition.Table 24. Configurat

AP440FX Motherboard Technical Product Specification381.15 EnvironmentalTable 25. Motherboard Environmental SpecificationsParameter SpecificationTemper

Motherboard Description391.16.1 Power Supply ConsiderationsThe AP440FX motherboard is designed to operate with a switching power supply in the PS/2fo

AP440FX Motherboard Technical Product Specificationiv1.15 Environmental...

AP440FX Motherboard Technical Product Specification401.17.1.5 EMKO-TSE (74-SEC) 207/94Summary of Nordic deviations to EN 60 950. (Norway, Sweden, De

412 Motherboard Resources2.1 Memory MapTable 28. Memory MapAddress Range(Decimal) Address Range (hex) Size Description1024K-131072K 100000-8000000 127

AP440FX Motherboard Technical Product Specification422.2 I/O MapTable 29. I/O MapAddress(hex) Size DescriptionAddress(hex) Size Description0000 - 000F

Motherboard Resources432.3 Soft-Off ControlThe motherboard design uses Soft-off control implemented under the SMM code in the BIOS.Any power supply us

AP440FX Motherboard Technical Product Specification442.6 InterruptsTable 32. InterruptsIRQ ResourceNMI I/O Channel Check0 Reserved, Interval Timer1 Re

453 Motherboard BIOS and Setup Utility3.1 IntroductionThe AP440FX motherboard uses an Intel BIOS, which is stored in flash memory and easilyupgraded

AP440FX Motherboard Technical Product Specification46The disk-based Flash upgrade utility, FMUP.EXE, has three options for BIOS upgrades:• The Flash

Motherboard BIOS and Setup Utility47PCI specification 2.1 for add-in card auto-configuration is also a part of the Plug and Play BIOS.Peer-to-peer hie

AP440FX Motherboard Technical Product Specification483.8 Advanced Power Management (APM)This section describes the use of System Management Mode (SMM

Motherboard BIOS and Setup Utility493.10 Language SupportThe BIOS setup screen and help messages are supported in 32 languages. There are 5 languages

Contentsv4 Error Messages and Beep Codes4.1 BIOS Beep Codes ...

AP440FX Motherboard Technical Product Specification50Table 35. Overview of the Setup Menu ScreensSetup Menu Screen DescriptionMain Set up and modify s

Motherboard BIOS and Setup Utility513.14.1.5 Primary IDE SlaveReports if an IDE device is connected to the computer. When selected, this brings up t

AP440FX Motherboard Technical Product Specification523.14.2.3 Floppy A: TypeSpecifies the physical size and capacity of the floppy drive. The option

Motherboard BIOS and Setup Utility533.14.3.3 HeadsIf IDE Device Configuration is set to User Definable, you must type the correct number of headsfor y

AP440FX Motherboard Technical Product Specification543.14.4 Boot Options SubscreenThis section describes the options available on the Boot Options su

Motherboard BIOS and Setup Utility553.14.4.7 Num LockSets the state of the Num Lock feature on your keyboard when you boot. The options are:• • Off

AP440FX Motherboard Technical Product Specification563.14.4.11 Typematic Rate DelaySets how long it takes (in milliseconds) for the key-repeat functi

Motherboard BIOS and Setup Utility573.14.5.2 Processor SpeedReports the microprocessor clock speed. There are no options.3.14.5.3 Cache SizeReports t

AP440FX Motherboard Technical Product Specification583.14.7.4 Serial Port 1 InterfaceConfigures serial port 1. The options are described and listed

Motherboard BIOS and Setup Utility593.14.7.7 Parallel Port InterfaceSelects the address and IRQ of the parallel port. The options are described and

AP440FX Motherboard Technical Product Specificationvi32. Interrupts ...

AP440FX Motherboard Technical Product Specification60Table 38 lists and describes the options that are available if the parallel port mode is ECP.Tabl

Motherboard BIOS and Setup Utility613.14.7.13 Secondary PCI IDE StatusDisplays the current status of the Secondary PCI IDE Interface from the selecta

AP440FX Motherboard Technical Product Specification623.14.8.4 Onboard Video IRQEnables or disables the onboard video IRQ. The options are:• Disable

Motherboard BIOS and Setup Utility633.14.8.8 Memory Error DetectionSets the type of error detection or correction. The options are:• Disabled (defa

AP440FX Motherboard Technical Product Specification643.14.9.4 Inactivity Timer (Minutes)Sets how long the computer must be inactive before it enters

Motherboard BIOS and Setup Utility653.14.10.3 ISA Shared Memory SizeSets a range of memory addresses that will be directed to the ISA bus rather than

AP440FX Motherboard Technical Product Specification663.14.10.5 IRQ 3, 4, 5, 7, 9, 10, 11, 12, 14, 15Sets the status of the IRQ. The options are:• A

Motherboard BIOS and Setup Utility673.14.11.5 Clear Event LogSets a flag that clears the event log on the next pass through the POST. The options ar

AP440FX Motherboard Technical Product Specification683.14.12 Security ScreenThis section describes the two access modes that can be set using the opti

Motherboard BIOS and Setup Utility693.14.13.4 Set Administrative PasswordSets the Administrative password. The password can be up to seven alphanume

71 Motherboard Description1.1 OverviewThe AP440FX motherboard is a 64-bit, high-performance, mixed-voltage, energy-conscious,highly integrated platfor

714 Error Messages and Beep Codes4.1 BIOS Beep CodesTable 41. BIOS Beep CodesBeeps Error Message Description1 Refresh Failure The memory refresh cir

AP440FX Motherboard Technical Product Specification72Table42. PCI Configuration Error Messages (continued)Error Message ExplanationNVRAM Cleared By Ju

Error Messages and Beep Codes734.3 BIOS Error MessagesTable 44. BIOS Error MessagesError Message ExplanationGate A20 Error Gate A20 on the keyboard c

AP440FX Motherboard Technical Product Specification744.4 ISA NMI MessagesTable 45. ISA NMI MessagesISA NMI Message ExplanationMemory Parity Error at

AP440FX Motherboard Technical Product Specification8OM06178LOQRPAASJKZ Y X WTUVMNABGDE HIFCFFHHJJGGCCBBDDIIEEKKLLMMFigure 1. Motherboard FeaturesTabl

Motherboard Description91.2 Motherboard Manufacturing OptionsContact your local Intel Field Sales Office for options and ordering information.1.3 For
