Technical Reference

Table 26. PCI Express Full-/Half-Mini Card Connector

Pin Signal Name Additional Signal Name

1 WAKE#

2 +3.3 V aux

3 Reserved

4 GND

5 Reserved

6 1.5 V

7 CLKREQ#

8 Reserved

9 GND

10 Reserved

11 REFCLK-

12 Reserved

13 REFCLK+

14 Reserved

15 GND

16 Reserved

17 Reserved

18 GND

19 Reserved

20 Reserved

21 GND

22 PERST#

23 PERn0

24 +3.3 V aux

25 PERp0

26 GND

27 GND

28 +1.5 V

29 GND

30 SMB_CLK

31 PETn0

32 SMB_DATA

33 PETp0

34 GND

35 GND

36 USB_D-

37 GND (mSATA) GND

38 USB_D+

continued
