Electrical Specifications

Datasheet 29

Table 3. Voltage Identification Definition

VID6 VID5 VID4 VID3 VID2 VID1 VID0 V

(V)

0 0 1 1 0 0 0 1.2000

0 0 1 1 0 0 1 1.1875

0 0 1 1 0 1 0 1.1750

0 0 1 1 0 1 1 1.1625

0 0 1 1 1 0 0 1.1500

0 0 1 1 1 0 1 1.1375

0 0 1 1 1 1 0 1.1250

0 0 1 1 1 1 1 1.1125

0 1 0 0 0 0 0 1.1000

0 1 0 0 0 0 1 1.0875

0 1 0 0 0 1 0 1.0750

0 1 0 0 0 1 1 1.0625

0 1 0 0 1 0 0 1.0500

0 1 0 0 1 0 1 1.0375

0 1 0 0 1 1 0 1.0250

0 1 0 0 1 1 1 1.0125

0 1 0 1 0 0 0 1.0000

0 1 0 1 0 0 1 0.9875

0 1 0 1 0 1 0 0.9750

0 1 0 1 0 1 1 0.9625

0 1 0 1 1 0 0 0.9500

0 1 0 1 1 0 1 0.9375

0 1 0 1 1 1 0 0.9250

0 1 0 1 1 1 1 0.9125

0 1 1 0 0 0 0 0.9000

0 1 1 0 0 0 1 0.8875

0 1 1 0 0 1 0 0.8750

0 1 1 0 0 1 1 0.8625

0 1 1 0 1 0 0 0.8500

0 1 1 0 1 0 1 0.8375

0 1 1 0 1 1 0 0.8250

0 1 1 0 1 1 1 0.8125

0 1 1 1 0 0 0 0.8000

0 1 1 1 0 0 1 0.7875

0 1 1 1 0 1 0 0.7750

0 1 1 1 0 1 1 0.7625

0 1 1 1 1 0 0 0.7500

0 1 1 1 1 0 1 0.7375
