Intel® Pentium® M ProcessorDatasheetApril 2004Order Number: 252612-003

10 IIntel® Pentium® M Processor DatasheetIntroductionThis page intentionally left blank.

Intel® Pentium® M Processor Datasheet 11Low Power Features2 Low Power Features2.1 Clock Control and Low Power StatesThe Intel Pentium M processor supp

12 Intel® Pentium® M Processor Datasheet Low Power FeaturesWhile in AutoHALT Powerdown state, the processor will process bus snoops. Stop-Grant StateW

Intel® Pentium® M Processor Datasheet 13Low Power FeaturesIf RESET# is driven active while the processor is in the Sleep state, and held active as spe

14 Intel® Pentium® M Processor Datasheet Low Power Features— If the target frequency is higher than the current frequency, Vcc is ramped up by placing

Intel® Pentium® M Processor Datasheet 15Low Power Features2.4 Processor Power Status Indicator (PSI#) SignalThe Intel Pentium M processor incorporates

16 IIntel® Pentium® M Processor DatasheetLow Power FeaturesThis page intentionally left blank.

Intel® Pentium® M Processor Datasheet 17Electrical Specifications3 Electrical Specifications3.1 System Bus and GTLREFThe Intel Pentium M processor sys

18 Intel® Pentium® M Processor Datasheet Electrical Specifications3.3.1 VCC DecouplingRegulator solutions need to provide bulk capacitance with a low

Intel® Pentium® M Processor Datasheet 19Electrical SpecificationsTable 2. Voltage Identification DefinitionVIDVCCVVIDVCCV543210 5432100000 0 01.7081

2 Intel® Pentium® M Processor Datasheet Information in this document is provided solely to enable use of Intel products. Intel assumes no liability wh

20 Intel® Pentium® M Processor Datasheet Electrical Specifications3.5 Catastrophic Thermal ProtectionThe Intel Pentium M processor supports the THERMT

Intel® Pentium® M Processor Datasheet 21Electrical SpecificationsNOTES:1. BPM[2:0]# and PRDY# are AGTL+ output only signals.2. In processor systems wh

22 Intel® Pentium® M Processor Datasheet Electrical Specifications3.9 Maximum RatingsTable 4 lists the processor’s maximum environmental stress rating

Intel® Pentium® M Processor Datasheet 23Electrical SpecificationsTable 5. Voltage and Current SpecificationsSymbol Parameter Min Typ Max Unit NotesVC

24 Intel® Pentium® M Processor Datasheet Electrical SpecificationsVCCLV13Low Voltage Intel Pentium M processor 1.30 GHz Core VCC for Enhanced Intel Sp

Intel® Pentium® M Processor Datasheet 25Electrical SpecificationsVCCULV9Ultra Low Voltage Intel Pentium M processor 900 MHzCore VCCfor Enhanced Intel

26 Intel® Pentium® M Processor Datasheet Electrical SpecificationsNOTES:1. The typical values shown are the VID encoded voltages. Static and Ripple to

Intel® Pentium® M Processor Datasheet 27Electrical SpecificationsTable 6. Voltage Tolerances for Intel Pentium M Processors with HFM VID = 1.484 V (A

28 Intel® Pentium® M Processor Datasheet Electrical SpecificationsFigure 2. Illustration of Active State VCC Static and Ripple Tolerances (Highest Fr

Intel® Pentium® M Processor Datasheet 29Electrical SpecificationsTable 7. Voltage Tolerances for Intel Pentium M Processors with HFM VID = 1.484 V (D

Intel® Pentium® M Processor Datasheet 3Contents1 Introduction ...

30 Intel® Pentium® M Processor Datasheet Electrical SpecificationsFigure 3. Illustration of Deep Sleep State Voltage Tolerances (Lowest Frequency Mod

Intel® Pentium® M Processor Datasheet 31Electrical SpecificationsTable 8. Voltage Tolerances for Intel Pentium M Processors with HFM VID = 1.388 V (A

32 Intel® Pentium® M Processor Datasheet Electrical SpecificationsTable 9. Voltage Tolerances for Intel Pentium M Processors with HFM VID = 1.388 V (

Intel® Pentium® M Processor Datasheet 33Electrical SpecificationsTable 10. Voltage Tolerances for Low Voltage Intel Pentium M Processors (Active Stat

34 Intel® Pentium® M Processor Datasheet Electrical SpecificationsTable 11. Voltage Tolerances for Low Voltage Intel Pentium M Processors (Deep Sleep

Intel® Pentium® M Processor Datasheet 35Electrical SpecificationsTable 12. Voltage Tolerances for Ultra Low Voltage Intel Pentium M Processors (Activ

36 Intel® Pentium® M Processor Datasheet Electrical SpecificationsTable 13. Voltage Tolerances for Ultra Low Voltage Intel Pentium M Processors (Deep

Intel® Pentium® M Processor Datasheet 37Electrical SpecificationsNOTES:1. Unless otherwise noted, all specifications in this table apply to all proces

38 Intel® Pentium® M Processor Datasheet Electrical Specifications.NOTES:1. Unless otherwise noted, all specifications in this table apply to all proc

Intel® Pentium® M Processor Datasheet 39Package Mechanical Specifications and Pin Information4 Package Mechanical Specifications and Pin InformationTh

4 Intel® Pentium® M Processor Datasheet Figures1 Clock Control States...

40 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationFigure 5. Micro-FCPGA Package - Top and Side ViewsNOTE:

Intel® Pentium® M Processor Datasheet 41Package Mechanical Specifications and Pin InformationFigure 6. Micro-FCPGA Package - Bottom ViewNOTE: All dim

42 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationTable 18. Micro-FCPGA Package DimensionsNOTE: Overall h

Intel® Pentium® M Processor Datasheet 43Package Mechanical Specifications and Pin InformationFigure 8. Micro-FCBGA Package Top and Bottom Isometric V

44 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationFigure 9. Micro-FCBGA Package Top and Side ViewsNOTE: A

Intel® Pentium® M Processor Datasheet 45Package Mechanical Specifications and Pin InformationTable 19. Micro-FCBGA Package DimensionsNOTE: Overall he

46 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationFigure 10. Micro-FCBGA Package Bottom ViewNOTE: All dime

Intel® Pentium® M Processor Datasheet 47Package Mechanical Specifications and Pin Information4.1 Processor Pin-Out and Pin ListFigure 11 on the next p

48 IIntel® Pentium® M Processor DatasheetPackage Mechanical Specifications and Pin InformationThis page intentionally left blank.Figure 11. The Coord

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 49 Table 20. Pin Listing by Pin NamePin NamePin NumberSi

Intel® Pentium® M Processor Datasheet 5Tables1 References ...

Package Mechanical Specifications and Pin Information 50 Intel® Pentium® M Processor Datasheet D[29]# H26 Source Synch Input/OutputD[30]# N25 Source

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 51 RS[2]# L2 Common Clock InputRSVD AF7 ReservedRSVD B2 R

Package Mechanical Specifications and Pin Information 52 Intel® Pentium® M Processor Datasheet VCC AD10 Power/OtherVCC AD12 Power/OtherVCC AD14 Power

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 53 VSS C18 Power/OtherVSS C21 Power/OtherVSS C24 Power/Ot

Package Mechanical Specifications and Pin Information 54 Intel® Pentium® M Processor Datasheet VSS R22 Power/OtherVSS R25 Power/OtherVSS T3 Power/Oth

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 55 VSS AE20 Power/OtherVSS AE23 Power/OtherVSS AE26 Power

Package Mechanical Specifications and Pin Information 56 Intel® Pentium® M Processor Datasheet AB10 VCC Power/OtherAB11 VSS Power/OtherAB12 VCC Power

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 57 AE10 VSS Power/OtherAE11 VCC Power/OtherAE12 VSS Power

Package Mechanical Specifications and Pin Information 58 Intel® Pentium® M Processor Datasheet C10 VSS Power/OtherC11 TMS CMOS InputC12 TDI CMOS Inpu

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 59 F10 VCCP Power/OtherF11 VSS Power/OtherF12 VCCP Power/

6 Intel® Pentium® M Processor Datasheet Revision HistoryDocument NumberRevision Description Date252612 001 Initial release of datasheet March 20032526

Package Mechanical Specifications and Pin Information 60 Intel® Pentium® M Processor Datasheet M2 DBSY# Common Clock Input/OutputM3 TRDY# Common Cloc

Package Mechanical Specifications and Pin InformationIntel® Pentium® M Processor Datasheet 61 V22 VCC Power/OtherV23 D[36]# Source Synch Input/Outpu

62 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin Information4.2 Alphabetical Signals ReferenceTable 22. Signal Des

Intel® Pentium® M Processor Datasheet 63Package Mechanical Specifications and Pin InformationCOMP[3:0] AnalogCOMP[3:0] must be terminated on the syst

64 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationDPSLP# InputDPSLP# when asserted on the platform causes

Intel® Pentium® M Processor Datasheet 65Package Mechanical Specifications and Pin InformationHIT#HITM#Input/OutputInput/OutputHIT# (Snoop Hit) and HI

66 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationPRDY# OutputProbe Ready signal used by debug tools to d

Intel® Pentium® M Processor Datasheet 67Package Mechanical Specifications and Pin InformationSLP# InputSLP# (Sleep), when asserted in Stop-Grant stat

68 Intel® Pentium® M Processor Datasheet Package Mechanical Specifications and Pin InformationTRDY# InputTRDY# (Target Ready) is asserted by the targ

Intel® Pentium® M Processor Datasheet 69Thermal Specifications and Design Considerations5 Thermal Specifications and Design ConsiderationsThe Intel Pe

Intel® Pentium® M Processor Datasheet 7Introduction1 IntroductionThis document provides electrical, mechanical, and thermal specifications for the Int

70 Intel® Pentium® M Processor Datasheet Thermal Specifications and Design ConsiderationsTable 23. Power Specifications for the Intel Pentium M Proce

Intel® Pentium® M Processor Datasheet 71Thermal Specifications and Design Considerations2. Not 100% tested. These power specifications are determined

72 Intel® Pentium® M Processor Datasheet Thermal Specifications and Design Considerations1. Intel does not support or recommend operation of the therm

Intel® Pentium® M Processor Datasheet 73Thermal Specifications and Design Considerations2.If the processor load-based Enhanced Intel SpeedStep technol

74 IIntel® Pentium® M Processor DatasheetThermal Specifications and Design ConsiderationsThis page intentionally left blank.

Intel® Pentium® M Processor Datasheet 75Debug Tools Specifications6 Debug Tools SpecificationsPlease refer to the ITP700 Debug Port Design Guide and

8 Intel® Pentium® M Processor Datasheet Introduction• Micro-op Fusion and Advanced Stack Management that reduce the number of micro-ops handled by the

Intel® Pentium® M Processor Datasheet 9Introduction1.2 ReferencesMaterial and concepts available in the following documents may be beneficial when rea
