Specification

Page 2-4

Special Features

 Support KBPO function – Keyboard power on, turn on the computer

from keyboard

 Support Wake-On-LAN by PME

 Support USB resume in S3

 Onboard Post Port LED display for system debugging

 Support Asynchronous clocking mode between FSB and PCI/PCI-E

 PowerBIOS for excellent overclocking features:

- Programmable FSB and PCI Clock output frequency with 1MHz fine

tuning

- Support BIOS adjustable CPU multiplier, FSB clock, PCI-E x16 clock,

DIMM frequency

- Support BIOS adjustable CPU Core voltage, Chipset voltage and DIMM

voltage

Form Factor

 305mm x 245 mm ATX size

Supported Operating System

 Windows 2000, Windows XP
