8 Intel
®
Server System SR1500AL User’s Guide
Configuration Jumpers
Figure 4. BIOS Select Jumper
Jumper Name Jumper Purpose
BIOS Select If pins 1-2 are jumpered, the BIOS in the lower bank will be selected
on the next reset. These pins should be jumpered on 2-3 for normal
operation.
TP02087
3
BIOS Select
1-2: Force
Lower Bank
2-3: Normal
Operation (Default)
3
J3H1
