Server System SR1500AL User’s Guide 45
Figure 36. Removing the Slimline Optical Drive Assembly from the Server
System
7. Press downward on the side of the tray (see letter “A”) and disengage the drive
from the two metal tabs on the opposite side of the tray.
8. Slide the optical drive out (see letter “B”) to remove it from the tray.
A
B
AF000384
